WebSocket Realtime

Real-time presentation control, room management, and collaboration API

Bidirectional WebSocket message streams between Cliqer server and clients

WebSocket Realtime API

Connect to wss://cliqer.io/ws for realtime presentation control and collaboration.

Auth: browsers authenticate automatically via the session_token session cookie sent on the upgrade request. Non-browser clients may pass the same session token as a ?token= query parameter or an Authorization: Bearer header. Connecting without a token is allowed, you join as a guest (you can view and join rooms but cannot become a host).

Connection

# WebSocket connections require a WebSocket client
# Using websocat for testing:
websocat "$WS_URL/ws?token=YOUR_ACCESS_TOKEN"

const ws = new WebSocket('$WS_URL/ws?token=' + accessToken)

ws.onopen = () => {
  console.log('Connected to Cliqer WebSocket')
}

ws.onmessage = (event) => {
  const message = JSON.parse(event.data)
  console.log('Received:', message)
}

ws.onerror = (error) => {
  console.error('WebSocket error:', error)
}

import websocket
import json

ws = websocket.WebSocketApp(
    f"$WS_URL/ws?token={access_token}",
    on_message=lambda ws, msg: print(json.loads(msg)),
    on_error=lambda ws, err: print(f"Error: {err}"),
    on_open=lambda ws: print("Connected")
)
ws.run_forever()

import (
    "github.com/gorilla/websocket"
)

url := "$WS_URL/ws?token=" + accessToken
conn, _, err := websocket.DefaultDialer.Dial(url, nil)
if err != nil {
    log.Fatal("dial:", err)
}
defer conn.Close()

for {
    _, message, err := conn.ReadMessage()
    if err != nil {
        break
    }
    fmt.Printf("Received: %s\n", message)
}

use WebSocket\Client;

$client = new Client("$WS_URL/ws?token={$accessToken}");

while (true) {
    $message = $client->receive();
    $data = json_decode($message, true);
    print_r($data);
}

use tokio_tungstenite::{connect_async, tungstenite::Message};
use futures_util::{StreamExt, SinkExt};

let url = format!("$WS_URL/ws?token={}", access_token);
let (mut ws_stream, _) = connect_async(&url).await?;

while let Some(msg) = ws_stream.next().await {
    match msg? {
        Message::Text(text) => {
            let data: serde_json::Value = serde_json::from_str(&text)?;
            println!("Received: {:?}", data);
        }
        _ => {}
    }
}

Room Management

Create Room

Create a new presentation room as host.

# Send via WebSocket connection
echo '{"type":"createRoom"}' | websocat "$WS_URL/ws?token=TOKEN"

ws.send(JSON.stringify({ type: 'createRoom' }))

ws.onmessage = (event) => {
  const msg = JSON.parse(event.data)
  if (msg.type === 'roomCreated') {
    console.log('Room ID:', msg.payload.roomId)
    console.log('Socket ID:', msg.payload.socketId)
  }
}

ws.send(json.dumps({"type": "createRoom"}))

# Response handler
def on_message(ws, message):
    msg = json.loads(message)
    if msg.get("type") == "roomCreated":
        print(f"Room ID: {msg['payload']['roomId']}")

msg := map[string]string{"type": "createRoom"}
conn.WriteJSON(msg)

var response map[string]interface{}
conn.ReadJSON(&response)
if response["type"] == "roomCreated" {
    payload := response["payload"].(map[string]interface{})
    fmt.Printf("Room ID: %s\n", payload["roomId"])
}

$client->send(json_encode(['type' => 'createRoom']));
$response = json_decode($client->receive(), true);

if ($response['type'] === 'roomCreated') {
    echo "Room ID: " . $response['payload']['roomId'];
}

let create_msg = serde_json::json!({"type": "createRoom"});
ws_stream.send(Message::Text(create_msg.to_string())).await?;

if let Some(Ok(Message::Text(text))) = ws_stream.next().await {
    let response: serde_json::Value = serde_json::from_str(&text)?;
    if response["type"] == "roomCreated" {
        println!("Room ID: {}", response["payload"]["roomId"]);
    }
}

Response:

{
  "type": "roomCreated",
  "payload": {
    "roomId": "ABC123",
    "socketId": "client_550e8400",
    "isPrimary": true
  }
}

Join Room

Join an existing presentation room.

echo '{"type":"joinRoom","payload":{"room":"ABC123","presenterName":"John","joinAsHost":false}}' | websocat "$WS_URL/ws?token=TOKEN"

ws.send(JSON.stringify({
  type: 'joinRoom',
  payload: {
    room: 'ABC123',
    presenterName: 'John Doe',
    joinAsHost: false
  }
}))

ws.send(json.dumps({
    "type": "joinRoom",
    "payload": {
        "room": "ABC123",
        "presenterName": "John Doe",
        "joinAsHost": False
    }
}))

msg := map[string]interface{}{
    "type": "joinRoom",
    "payload": map[string]interface{}{
        "room":          "ABC123",
        "presenterName": "John Doe",
        "joinAsHost":    false,
    },
}
conn.WriteJSON(msg)

$client->send(json_encode([
    'type' => 'joinRoom',
    'payload' => [
        'room' => 'ABC123',
        'presenterName' => 'John Doe',
        'joinAsHost' => false
    ]
]));

let join_msg = serde_json::json!({
    "type": "joinRoom",
    "payload": {
        "room": "ABC123",
        "presenterName": "John Doe",
        "joinAsHost": false
    }
});
ws_stream.send(Message::Text(join_msg.to_string())).await?;

Response:

{
  "type": "joinedRoom",
  "payload": {
    "id": "client_550e8400",
    "hosts": ["host_abc123"],
    "needsRefresh": false
  }
}

Connection & Room Flow

Slide Navigation

Control slide navigation in real-time.

Event	Description	Payload
`webAction`	Navigate slides	`{ action: 'next' \| 'prev' \| 'goto', slide?: number }`
`clicksEnabled`	Toggle click control for one client (host only)	Send `{ to: string, enabled: boolean }`. Rebroadcast to the target as a bare boolean payload, not an object
`countdown`	Timer control	`{ type: 'start' \| 'stop', time: number }`
`presenterMouse`	Laser pointer	`{ mouse: { x: number, y: number }, color?: string }`
`needsRefresh`	Request refresh	`{ forId: string }`
`refreshRoom`	Roll room to a new link (host only)	(no payload, server assigns a new room id)

# Next slide
echo '{"type":"webAction","payload":{"action":"next"}}' | websocat "wss://..."
# Previous slide
echo '{"type":"webAction","payload":{"action":"prev"}}' | websocat "wss://..."
# Go to slide 5
echo '{"type":"webAction","payload":{"action":"goto","slide":5}}' | websocat "wss://..."

// Next slide
ws.send(JSON.stringify({
  type: 'webAction',
  payload: { action: 'next' }
}))

// Previous slide
ws.send(JSON.stringify({
  type: 'webAction',
  payload: { action: 'prev' }
}))

// Go to specific slide
ws.send(JSON.stringify({
  type: 'webAction',
  payload: { action: 'goto', slide: 5 }
}))

// Laser pointer
ws.send(JSON.stringify({
  type: 'presenterMouse',
  payload: { mouse: { x: 0.5, y: 0.3 }, color: '#ef4444' }
}))

# Next slide
ws.send(json.dumps({
    "type": "webAction",
    "payload": {"action": "next"}
}))

# Previous slide
ws.send(json.dumps({
    "type": "webAction",
    "payload": {"action": "prev"}
}))

# Go to specific slide
ws.send(json.dumps({
    "type": "webAction",
    "payload": {"action": "goto", "slide": 5}
}))

// Next slide
conn.WriteJSON(map[string]interface{}{
    "type":    "webAction",
    "payload": map[string]string{"action": "next"},
})

// Previous slide
conn.WriteJSON(map[string]interface{}{
    "type":    "webAction",
    "payload": map[string]string{"action": "prev"},
})

// Next slide
$client->send(json_encode([
    'type' => 'webAction',
    'payload' => ['action' => 'next']
]));

// Go to specific slide
$client->send(json_encode([
    'type' => 'webAction',
    'payload' => ['action' => 'goto', 'slide' => 5]
]));

// Next slide
let next_msg = serde_json::json!({
    "type": "webAction",
    "payload": {"action": "next"}
});
ws_stream.send(Message::Text(next_msg.to_string())).await?;

// Go to specific slide
let goto_msg = serde_json::json!({
    "type": "webAction",
    "payload": {"action": "goto", "slide": 5}
});
ws_stream.send(Message::Text(goto_msg.to_string())).await?;

Messaging

Send messages between hosts and clients.

# Message to hosts (from client)
echo '{"type":"messageToHosts","payload":{"text":"Question about slide 3"}}' | websocat "wss://..."
# Message to clients (from host)
echo '{"type":"messageToClients","payload":{"text":"Welcome everyone!"}}' | websocat "wss://..."

// Client sends message to hosts
ws.send(JSON.stringify({
  type: 'messageToHosts',
  payload: { text: 'Question about slide 3' }
}))

// Host sends message to all clients
ws.send(JSON.stringify({
  type: 'messageToClients',
  payload: { text: 'Welcome everyone!' }
}))

// Listen for messages
ws.onmessage = (event) => {
  const msg = JSON.parse(event.data)
  if (msg.type === 'messageFromHost') {
    console.log(`Host says: ${msg.payload.originalPayload.text}`)
  }
  if (msg.type === 'messageFromClient') {
    console.log(`${msg.payload.fromPresenterName}: ${msg.payload.originalPayload.text}`)
  }
}

# Client sends message to hosts
ws.send(json.dumps({
    "type": "messageToHosts",
    "payload": {"text": "Question about slide 3"}
}))

# Host sends message to all clients
ws.send(json.dumps({
    "type": "messageToClients",
    "payload": {"text": "Welcome everyone!"}
}))

// Message to hosts
conn.WriteJSON(map[string]interface{}{
    "type": "messageToHosts",
    "payload": map[string]string{"text": "Question about slide 3"},
})

// Message to clients (as host)
conn.WriteJSON(map[string]interface{}{
    "type": "messageToClients",
    "payload": map[string]string{"text": "Welcome everyone!"},
})

// Message to hosts
$client->send(json_encode([
    'type' => 'messageToHosts',
    'payload' => ['text' => 'Question about slide 3']
]));

// Message to clients (as host)
$client->send(json_encode([
    'type' => 'messageToClients',
    'payload' => ['text' => 'Welcome everyone!']
]));

// Message to hosts
let msg = serde_json::json!({
    "type": "messageToHosts",
    "payload": {"text": "Question about slide 3"}
});
ws_stream.send(Message::Text(msg.to_string())).await?;

Incoming Message Format:

{
  "type": "messageFromHost",
  "payload": {
    "fromClientId": "host_abc123",
    "fromPresenterName": "Host",
    "originalPayload": { "text": "Welcome everyone!" }
  }
}

Event Reference

Outgoing Events (Client → Server)

Event	Description
`createRoom`	Create a new room
`joinRoom`	Join existing room
`webAction`	Slide navigation
`clicksEnabled`	Toggle click control
`countdown`	Timer control
`presenterMouse`	Laser pointer position
`messageToHosts`	Send message to hosts
`messageToClients`	Send message to clients (host only)
`needsRefresh`	Request refresh for specific client
`refreshRoom`	Roll the host onto a brand-new room id (host only); the existing audience stays in the old room
`closeStream`	Stop one client's screen share (host only); requires a `to` target and is a no-op without one
`logout`	Leave the room and release the host's licence seat; the socket itself stays open

Incoming Events (Server → Client)

Event	Description
`connected`	Sent on open with `{ clientId, userId, isAuthenticated }`
`roomCreated`	Room creation confirmed
`joinedRoom`	Successfully joined room
`clientJoined`	New client joined room
`clientLeft`	A client left the room
`webAction`	Slide navigation event
`clicksEnabled`	Click control toggled
`countdown`	Timer event
`presenterMouse`	Laser pointer position
`messageFromHost`	Message from host
`messageFromClient`	Message from client
`needsRefresh`	Host requested this client refresh
`refreshRoomResult`	Result of a `refreshRoom`, carries the new room id (sent to the requesting host, followed by `hostInfo`)
`logout`	Disconnection notice
`error`	Error message
