NDI Output
Broadcast the Cliqer timer and every remote caller as NDI sources for vMix, OBS, Wirecast, and other NDI-compatible production software.
The desktop app sends the timer to your network as an NDI source called Cliqer Timer, and Studio sends its Program, outputs and each remote caller as NDI sources too. Any NDI receiver on the same network can pick them up.
NDI is on Plus, Pro and above, the Event Pass and the Free trial. Compare plans.
The timer's NDI settings (size, frame rate, alpha channel, digit size) are in Timer: NDI output. Studio's NDI outputs are in Outputs.
Receiving the NDI source
vMix
- Click Add Input, then NDI / Desktop Capture.
- Select the Cliqer source from the list.
OBS Studio
- Install the obs-ndi plugin.
- Add an NDI Source to your scene and select the Cliqer source.
Wirecast and TriCaster
Add an NDI source with the usual NDI input in your production software.
Troubleshooting
The source does not appear
- Keep Cliqer and the production software on the same network.
- NDI finds sources over mDNS, so check no firewall blocks it. On macOS, Cliqer needs Local Network permission, see Permissions.
- If the NDI controls are greyed out, install NDI Tools and restart Cliqer.
See also: Timer · vMix Integration
